Sensilink B-ID1

Built on low-power BLE broadcasting technology, it provides secure and continuous ID transmission with extremely low energy consumption.The device periodically broadcasts a customizable identifier (ID), allowing gateways, smartphones, or BLE-enabled systems to detect and process the signal for asset tracking, personnel presence monitoring, access control, workflow automation, or location-based services. Its robust enclosure and stable RF performance ensure consistent communication even in challenging environments.

Data sheet Contact sales

Temperature range: -40°C to +85°C
Battery life up to 20 years
IP68 housing for harsh environments

Available references

For complete reference list, please refer to the product data sheet.

B-ID1

Battery

Type: 3 VDC internal lithium battery
Battery life: Up to 20 years (configuration dependent)

Radio & protocols

2.4 GHz – Bluetooth Low Energy 4.0/4.2 compatible
Transmission power: up to +4 dBm (configurable)
NFC-based configuration
Over-the-air firmware update (OTA)

Radio frame format

iBeacon
Eddystone
Sensilink or Customize frame format

Case & dimensions

Robust food-grade case (POM-C)
Diameter: Base:Ø57mm Top:Ø40mm Thickness:19mm
Weight: 45 g
Operating temperature: -40°C to +85°C
Protection class: IP68

Certifications(In process)

CE / UKCA
FCC / IC
RoHS compliant

Download the latest documents to integrate and deploy the B-ID1 in your IoT infrastructure.

Data sheet User guide Frame specifications

Mounting & installation

Sensors Holder with industrial adhesive sticker
Mounting bracket for wall or asset installation
Nylon cable tie mounting kit

Configuration & commissioning

Sensilink NFC reader
Mobile commissioning application

Firmware customization

Adapt the BLE frame format to your platform and business logic. Sensilink engineering teams can:

Customize advertising frames and payload structure
Pre-configure thresholds, logging modes and transmission intervals
Align device identifiers with your asset management system

Label & branding

Create a fully branded sensor fleet with customized labels and markings:

White-label logos, corporate colors and QR codes
Printed asset IDs and installation instructions
Custom packaging for integrators and OEM partners

Use cases

Temperature monitoring for pharmaceutical products

Temperature monitoring of pharmaceutical products

Ensure compliance and patient safety by continuously monitoring storage temperatures for vaccines, biologics and other temperature-sensitive medicines.

Remote temperature monitoring during transport

Track the temperature of refrigerated trucks, containers and last mile deliveries using Sensilink BLE sensors combined with gateways and cloud dashboards.
